| Machine tool model | YF-NSP2020B | YF-NSP2025B | YF-NSP2030B | YF-NSP2035B | YF-NSP2040B |
| X / Y axis stroke Unit：mm | 2200/2000 | 2700/2000 | 3200/2000 | 3700/2000 | 4200/2000 |
| Z-axis travel Unit:mm | 800 | 800 | 800 | 800 | 800 |
| Distance from spindle end face to worktable Unit:mm | 170-970 | 170-970 | 170-970 | 170-970 | 170-970 |
| Table area Unit:mm | 2000*1800 | 2500*1800 | 3000*1800 | 3500*1800 | 4000*1800 |
| Gantry width Unit:mm | 2000 | 2000 | 2000 | 2000 | 2000 |
| Table bearing Unit:kg | 6000 | 7000 | 8000 | 9000 | 10000 |
| Screw diameter specification（X/Y/Z） | Standard configuration (included) | Standard configuration (included) | Standard configuration (included) | Standard configuration (included) | Standard configuration (included) |
| Wire gauge specification（X/Y/Z） | 63/50/50 | 63/50/50 | 80/50/50 | 80/50/50 | 80/50/50 |
| principal axis | BT50 | BT50 | BT50 | BT50 | BT50 |
| Three axis motor torque（X/Y/Z） | 40/30/30 | 40/30/30 | 50/30/30 | 50/30/30 | 50/30/30 |
| Spindle motor power Unit:KW | 22 | 22 | 22 | 22 | 22 |
| Maximum spindle speed Unit:rpm | 6000/18000 | 6000/18000 | 6000/18000 | 6000/18000 | 6000/18000 |
| Tool magazine | Optional | Optional | Optional | Optional | Optional |
| system | Fanuc / Siemens | Fanuc / Siemens | Fanuc / Siemens | Fanuc / Siemens | Fanuc / Siemens |
| Machine weight Unit:T | 20 | 20.5 | 21 | 21.5 | 22 |
| Linear accuracy Unit:mm | 0.01/2000 | 0.01/2000 | 0.01/2000 | 0.01/2000 | 0.01/2000 |
| positioning accuracy Unit:mm | 0.01/1000 | 0.01/1000 | 0.01/1000 | 0.01/1000 | 0.01/1000 |
| Repeat positioning accuracy Unit:mm | 0.005/1000 | 0.005/1000 | 0.005/1000 | 0.005/1000 | 0.005/1000 |
| area covered Unit:mm | 5500/3800/3200 | 5500/4300/3200 | 5500/4800/3200 | 5500/5300/3200 | 5500/5800/3200 |
| Spindle oil cooler | Standard configuration (included) | Standard configuration (included) | Standard configuration (included) | Standard configuration (included) | Standard configuration (included) |
| Chip conveyor | Standard configuration (included) | Standard configuration (included) | Standard configuration (included) | Standard configuration (included) | Standard configuration (included) |
| High pressure water pump | Standard configuration (included) | Standard configuration (included) | Standard configuration (included) | Standard configuration (included) | Standard configuration (included)） |
